Part Number

EKI-2720G-4F-AE

EKI-2720G-4FI-AE

Certification

EMC

EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)

EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)

EMI

CE, FCC Class A

CE, FCC Class A

Freefall

IEC 60068-2-32

IEC 60068-2-32

Safety

UL 61010

UL 61010

Shock

IEC 60068-2-27

IEC 60068-2-27

Vibration

IEC 60068-2-6

IEC 60068-2-6

Environment

Relative Humidity (Non-condensing)

10 ~ 95%

10 ~ 95%

Temperature (Operating range)

-10 ~ 60° C (14 ~ 140° F)

-40 ~ 75° C (-40 ~ 167° F)

Temperature (Storage range)

- 40 ~ 85° C (-40 ~185° F)

- 40 ~ 85° C (-40 ~185° F)

Power Requirement (X)

Connectors

6-pin removable screw terminal ((power & relay)

6-pin removable screw terminal ((power & relay)

Operating Current

0.25A @ 48Vdc (system)

0.25A @ 48Vdc (system)

Operating Voltage

12 ~ 48 VDC

12 ~ 48 VDC

Power budget

90W

90W

Reverse Polarity

Present

Present

* Port Configuration

Ethernet Port Description

16 x 10/100/1000Base-T(X)

16 x 10/100/1000Base-T(X)

Ethernet Transmission Distance (X)

100 m

100 m

Fiber Port Description

4 x SFP(mini-GBIC) ports

4 x SFP(mini-GBIC) ports

Fiber Port Interface (X)

SFP

SFP

Fiber Transmission Distance (X)

Up to 110km

Up to 110km

Communication (XX)

IEEE Standard

IEEE 802.1p, 802.3ad, 802.1x,802.1D, 802.1s, 802.1w

IEEE 802.1p, 802.3ad, 802.1x,802.1D, 802.1s, 802.1w

Mechanism

Dimensions (W x H x D)

74 x 152 x 105 mm (2.91" x 5.98" x 4.13")

74 x 152 x 105 mm (2.91" x 5.98" x 4.13")

Enclosure

Metal

Metal

IP Rating

IP30

IP30

Mounting (X)

DIN-rail, Wall

DIN-rail, Wall

Weight

1.1kg

1.1kg

Switch Properties

Jumbo Frame

9,216 bytes

9,216 bytes

MAC Table Size

8K

8K

Packet Buffer Size

4.1M bit

4.1M bit

Switch Fabric Speed

40Gbps

40Gbps

General (X)

Ethernet Connectors

16 x RJ-45 + 4 x SFP ports

16 x RJ-45 + 4 x SFP ports

Interface (...)

Ports Number

20

20

Power Supply (X)

Power Input

12 ~ 48 VDC

12 ~ 48 VDC
