Part Number

ACP-4020BP-25ZE

ACP-4020BP-30ZE

ACP-4020BP-40ZE

ACP-4020MB-25ZE

ACP-4020MB-30ZE

ACP-4020MB-40ZE

Form Factor

Form Factor

4U Rackmount

4U Rackmount

4U Rackmount

4U Rackmount

4U Rackmount

4U Rackmount

Cooling

Air Filter

Yes

Yes

Yes

Yes

Yes

Yes

Fan

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

System Fan

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

2 (9 cm / 53 CFM)

Front I/O Interface

USB3.0

2

2

2

2

2

2

Environment

Operating-Temperature

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

0 ~ 45

Non-Operational Temperature

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

Operating Shock

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

Operating Humidity

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

Non-Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Operating Vibration (5 ~ 500 Hz)

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

1 Grms

Non-Operating Vibration (5 ~ 500 Hz)

2 G

2 G

2 G

2 G

2 G

2 G

Physical Characteristics

Weight

8.5 kg (18.7 lb)

8.5 kg (18.7 lb)

8.5 kg (18.7 lb)

8.5 kg (18.7 lb)

8.5 kg (18.7 lb)

8.5 kg (18.7 lb)

Dimensions (W x H x D)

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

482 x 177 x 348 mm (19'' x 7.0'' x 13.7'')

Disk Drive Bay

Slim ODD

1

1

1

1

1

1

2.5" Internal

2

2

2

2

2

2

3.5 External Bay

1

1

1

1

1

1

Miscellaneous

LED Indicators

Power, HDD, temperature, fan, LAN1, and LAN2

Power, HDD, temperature, fan, LAN1, and LAN2

Power, HDD, temperature, fan, LAN1, and LAN2

Power, HDD, temperature, fan, LAN1, and LAN2

Power, HDD, temperature, fan, LAN1, and LAN2

Power, HDD, temperature, fan, LAN1, and LAN2

Rear Panel

One 9-pin D-Sub opening

One 9-pin D-Sub opening

One 9-pin D-Sub opening

One 9-pin D-Sub opening

One 9-pin D-Sub opening

One 9-pin D-Sub opening

Intelligent System Module

Remote Monitoring

CPU/System fan speed , CPU/System temperature , motherboard voltage

CPU/System fan speed , CPU/System temperature , motherboard voltage

CPU/System fan speed , CPU/System temperature , motherboard voltage

CPU/System fan speed , CPU/System temperature , motherboard voltage

CPU/System fan speed , CPU/System temperature , motherboard voltage

CPU/System fan speed , CPU/System temperature , motherboard voltage

Power Supply

Power Supply

250W (Single)

300W (Single)

400W (Single)

250W (Single)

300W (Single)

400W (Single)
