Part Number

IPC-7220-00BE

IPC-7220-30BE

IPC-7220-40BE

Front I/O Interface

PS/2

2 (1 x Keyboard, 1 x Mouse)

2 (1 x Keyboard, 1 x Mouse)

2 (1 x Keyboard, 1 x Mouse)

USB

2

2

2

Cooling

Air Filter

Yes

Yes

Yes

Fan

1 (12 cm / 85 CFM)

1 (12 cm / 85 CFM)

1 (12 cm / 85 CFM)

Environment

Operating-Temperature

0 ~ 45

0 ~ 45

0 ~ 45

Non-Operational Temperature

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

-20 ~ 60° C (-4 ~ 140° F)

Operating Shock

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

10 G (with 11 ms duration, half sine wave)

Operating Humidity

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

10 ~ 85% @ 40° C, non-condensing

Non-Operating Humidity

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

10 ~ 95% @ 40° C, non-condensing

Operating Vibration (5 ~ 500 Hz)

1 Grms

1 Grms

1 Grms

Non-Operating Vibration (5 ~ 500 Hz)

2 G

2 G

2 G

Physical Characteristics

Weight

14 kg (30.8 lb)

14 kg (30.8 lb)

14 kg (30.8 lb)

Dimensions (W x H x D)

200 x 320 x 480 mm (7.9" x 12.6" x 18.9")

200 x 320 x 480 mm (7.9" x 12.6" x 18.9")

200 x 320 x 480 mm (7.9" x 12.6" x 18.9")

Disk Drive Bay

5.25" Front-Accessible

2

2

2

Miscellaneous

LED Indicators

Power, HDD, temperature, fan

Power, HDD, temperature, fan

Power, HDD, temperature, fan

Control

Power Switch, System reset, Alarm reset

Power Switch, System reset, Alarm reset

Power Switch, System reset, Alarm reset

Rear Panel

Reserved Two 9-pin D-Sub openings, one LPT opening

Reserved Two 9-pin D-Sub openings, one LPT opening

Reserved Two 9-pin D-Sub openings, one LPT opening

Power Supply

Power Supply

-

300W (Single)

400W (Single)
