Part Number

TPC-1751T-E3AE

TPC-1751T-J3AE

General

Power Consumption

43.2 W (Typical)

43.2 W (Typical)

Power Input

24VDC +/- 20%

24VDC +/- 20%

Watchdog Timer

1 ~ 255 sec (system)

1 ~ 255 sec (system)

Mounting

Desktop, Wall, Panel Mount, and VESA or stand mount (with optional kit)

Desktop, Wall, Panel Mount, and VESA or stand mount (with optional kit)

Certifications

BSMI, CCC, CE, FCC Class A, UL, EAC

BSMI, CCC, CE, FCC Class A, UL, EAC

Dimensions (W x H x D)

413.7 x 347.2 x 63.8 (16.28" x 13.68" x 2.5")

413.7 x 347.2 x 63.8 (16.28" x 13.68" x 2.5")

BIOS

AMI UEFI

AMI UEFI

Cooling System

Fanless design

Fanless design

Enclosure

Front bezel: Die-cast Aluminum alloy, Back housing: SECC

Front bezel: Die-cast Aluminum alloy, Back housing: SECC

OS Support

Microsoft® WES7 32bit/64bit / WE8S 64bit / Windows 7/ 8.1 32bit/64bit / Windows 10 Enterprise LTSB

Microsoft® WES7 32bit/64bit / WE8S 64bit / Windows 7/ 8.1 32bit/64bit / Windows 10 Enterprise LTSB

Weight (Net)

4 kg

4 kg

System Hardware

CPU

Intel® Atom? E3827 1.75 GHz Processor

Intel® Celeron J1900 2 GHz Processor

Memory

1 x SO-DIMM with 4GB DDR3L SDRAM (supports up to 8G)

1 x SO-DIMM with 4GB DDR3L SDRAM (supports up to 8G)

Storage

CFast slot x 1, 2.5" SATA SSD slot x 1 (optional)

CFast slot x 1, 2.5" SATA SSD slot x 1 (optional)

LAN

10/100/1000Base-T x 2

10/100/1000Base-T x 2

Expansion Slots

Full-size Mini PCI-E

Full-size Mini PCI-E

I/O

RS-232 x 1, RS-232/422/485 x 1, USB3.0 x 1, USB2.0 x 1

RS-232 x 1, RS-232/422/485 x 1, USB3.0 x 1, USB2.0 x 1

LCD Display

Viewing Angle (H/V°)

160/140

160/140

Luminance (cd/m2)

350

350

Contrast Ratio

800:1

800:1

Max. Resolution

1280 x 1024

1280 x 1024

Max. Colors

16.7 M

16.7 M

Display Type

SXGA TFT LED LCD

SXGA TFT LED LCD

Display Size

17"

17"

Backlight Life

50, 000 hrs

50, 000 hrs

Environment

Ingress Protection

Front panel: IP66

Front panel: IP66

Vibration Protection

With CFast: 2 Grms (5~500 Hz), With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)

With CFast: 2 Grms (5~500 Hz), With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)

Operating Temperature

-20 ~ 60°C (-4 ~ 140°F)

0 ~ 50°C (32 ~ 122°F)

Storage Temperature

-30 ~ 70°C (-22 ~ 158°F)

-20 ~ 60°C (-4 ~ 140°F)

Humidity

10 ~ 90% RH @ 40°C, non-condensing

10 ~ 90% RH @ 40°C, non-condensing

Touchscreen

Lifespan

36 million touches at single point

36 million touches at single point

Light Transmission

Above 75%

Above 75%

Resolution

Linearity

Linearity

Type

5-wire, analog resistive

5-wire, analog resistive
