Part Number |
UNO-2484G-7331AE |
UNO-2484G-7332AE |
UNO-2484G-7531AE |
UNO-2484G-7532AE |
UNO-2484G-7731AE |
UNO-2484G-7732AE |
Environment |
||||||
Ingress Protection |
IP40 |
IP40 |
IP40 |
IP40 |
IP40 |
IP40 |
Operating Temperature |
-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow |
-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow |
-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow |
-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow |
-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow |
-20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow |
Relative Humidity |
10 ~ 95% @ 40° C (non-condensing) |
10 ~ 95% @ 40° C (non-condensing) |
10 ~ 95% @ 40° C (non-condensing) |
10 ~ 95% @ 40° C (non-condensing) |
10 ~ 95% @ 40° C (non-condensing) |
10 ~ 95% @ 40° C (non-condensing) |
Shock Protection |
Operating, IEC 60068-2-27, 50G, half sine, 11ms |
Operating, IEC 60068-2-27, 50G, half sine, 11ms |
Operating, IEC 60068-2-27, 50G, half sine, 11ms |
Operating, IEC 60068-2-27, 50G, half sine, 11ms |
Operating, IEC 60068-2-27, 50G, half sine, 11ms |
Operating, IEC 60068-2-27, 50G, half sine, 11ms |
Storage Temperature |
-40 ~ 85°C (-40~185°F) |
-40 ~ 85°C (-40~185°F) |
-40 ~ 85°C (-40~185°F) |
-40 ~ 85°C (-40~185°F) |
-40 ~ 85°C (-40~185°F) |
-40 ~ 85°C (-40~185°F) |
Vibration Protection |
Operating, IEC 60068-2-64, 3 Grms, random, 5 ~ 500Hz, 1 hr/axis |
Operating, IEC 60068-2-64, 3 Grms, random, 5 ~ 500Hz, 1 hr/axis |
Operating, IEC 60068-2-64, 3 Grms, random, 5 ~ 500Hz, 1 hr/axis |
Operating, IEC 60068-2-64, 3 Grms, random, 5 ~ 500Hz, 1 hr/axis |
Operating, IEC 60068-2-64, 3 Grms, random, 5 ~ 500Hz, 1 hr/axis |
Operating, IEC 60068-2-64, 3 Grms, random, 5 ~ 500Hz, 1 hr/axis |
General |
||||||
Certifications |
CE, FCC, UL, CCC, BSMI |
CE, FCC, UL, CCC, BSMI |
CE, FCC, UL, CCC, BSMI |
CE, FCC, UL, CCC, BSMI |
CE, FCC, UL, CCC, BSMI |
CE, FCC, UL, CCC, BSMI |
Dimensions (W x H x D) |
252 x 149 x 62 mm (9.9" x 5.9" x 2.4") |
252 x 149 x 62 mm (9.9" x 5.9" x 2.4") |
252 x 149 x 62 mm (9.9" x 5.9" x 2.4") |
252 x 149 x 62 mm (9.9" x 5.9" x 2.4") |
252 x 149 x 62 mm (9.9" x 5.9" x 2.4") |
252 x 149 x 62 mm (9.9" x 5.9" x 2.4") |
Enclosure |
Aluminum Housing |
Aluminum Housing |
Aluminum Housing |
Aluminum Housing |
Aluminum Housing |
Aluminum Housing |
Power Consumption |
28W (Typical), 72W(Max) |
28W (Typical), 72W(Max) |
28W (Typical), 72W(Max) |
28W (Typical), 72W(Max) |
28W (Typical), 72W(Max) |
28W (Typical), 72W(Max) |
Power Requirement |
24VDC ± 20% |
24VDC ± 20% |
24VDC ± 20% |
24VDC ± 20% |
24VDC ± 20% |
24VDC ± 20% |
Weight (Net) |
1.6kg (3.5lbs) |
1.6kg (3.5lbs) |
1.6kg (3.5lbs) |
1.6kg (3.5lbs) |
1.6kg (3.5lbs) |
1.6kg (3.5lbs) |
OS Support |
Windows 10, Advantech Linux |
Microsoft® Windows 7/8 |
Microsoft® Windows 7/8 |
Microsoft® Windows 7/8 |
Microsoft® Windows 7/8 |
Microsoft® Windows 7/8 |
Form factor |
Regular Size with stackable design |
Regular Size with stackable design |
Regular Size with stackable design |
Regular Size with stackable design |
Regular Size with stackable design |
Regular Size with stackable design |
Mounting |
Stand, Wall, VESA (Optional), Din-rail (Optional) |
Stand, Wall, VESA (Optional) |
Stand, Wall, VESA (Optional) |
Stand, Wall, VESA (Optional) |
Stand, Wall, VESA (Optional) |
Stand, Wall, VESA (Optional) |
I/O Interface |
||||||
Audio |
Line-In, Line-Out |
Line-In, Line-Out |
Line-In, Line-Out |
Line-In, Line-Out |
Line-In, Line-Out |
Line-In, Line-Out |
Displays |
1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp |
1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp |
1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp |
1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp |
1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp |
1 x VGA, supports 1920x1200@60Hz 24bpp, 1 x HDMI 1.4a, supports 3200x2000@60Hz 24bpp |
Grounding Protection |
Chassis Grounding |
Chassis Grounding |
Chassis Grounding |
Chassis Grounding |
Chassis Grounding |
Chassis Grounding |
LAN |
4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet |
4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet |
4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet |
4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet |
4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet |
4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet |
Power Connector |
1 x 3 Pins, Terminal Block |
1 x 3 Pins, Terminal Block |
1 x 3 Pins, Terminal Block |
1 x 3 Pins, Terminal Block |
1 x 3 Pins, Terminal Block |
1 x 3 Pins, Terminal Block |
Serial Ports |
2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps |
2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps |
2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps |
2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps |
2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps |
2x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps |
USB Port |
4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant) |
4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant) |
4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant) |
4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant) |
4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant) |
4 x USB Ports (2 x USB2.0, 2 x USB3.0 compliant) |
System Hardware |
||||||
BIOS |
AMI UEFI 128Mbit Flash BIOS |
AMI UEFI 128Mbit Flash BIOS |
AMI UEFI 128Mbit Flash BIOS |
AMI UEFI 128Mbit Flash BIOS |
AMI UEFI 128Mbit Flash BIOS |
AMI UEFI 128Mbit Flash BIOS |
Expansion |
2 x Full-size mPCIe slot, mPCIe 2.0 |
2 x Full-size mPCIe slot, mPCIe 2.0 |
2 x Full-size mPCIe slot, mPCIe 2.0 |
2 x Full-size mPCIe slot, mPCIe 2.0 |
2 x Full-size mPCIe slot, mPCIe 2.0 |
2 x Full-size mPCIe slot, mPCIe 2.0 |
Graphics Engine |
Intel® HD Graphics 5000/4400 |
Intel® HD Graphics 5000/4400 |
Intel® HD Graphics 5000/4400 |
Intel® HD Graphics 5000/4400 |
Intel® HD Graphics 5000/4400 |
Intel® HD Graphics 5000/4400 |
LED Indicators |
LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD |
LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD |
LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD |
LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD |
LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD |
LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD |
Memory |
On-board 4GB DDR3L 1333/1600 MHz |
On-board 4GB DDR3L 1333/1600 MHz |
On-board 4GB DDR3L 1333/1600 MHz |
On-board 4GB DDR3L 1333/1600 MHz |
On-board 4GB DDR3L 1333/1600 MHz |
On-board 4GB DDR3L 1333/1600 MHz |
Processor |
Intel® 4th Gen Core? i7-4650U ULT 1.7 GHz Dual Core, 4MB L2 |
Intel® 4th Gen Core? i7-4650U ULT 1.7 GHz Dual Core, 4MB L2 |
Intel® 4th Gen Core? i7-4650U ULT 1.7 GHz Dual Core, 4MB L2 |
Intel® 4th Gen Core? i7-4650U ULT 1.7 GHz Dual Core, 4MB L2 |
Intel® 4th Gen Core? i7-4650U ULT 1.7 GHz Dual Core, 4MB L2 |
Intel® 4th Gen Core? i7-4650U ULT 1.7 GHz Dual Core, 4MB L2 |
Storage |
One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional) |
One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional) |
One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional) |
One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional) |
One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional) |
One mSATA, Two drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD), CFast drive by iDoor Technology (Optional) |
System Chip |
Integrated Intel 8 Series Chipset |
Integrated Intel 8 Series Chipset |
Integrated Intel 8 Series Chipset |
Integrated Intel 8 Series Chipset |
Integrated Intel 8 Series Chipset |
Integrated Intel 8 Series Chipset |
Watchdog Timer |
Programmable 256 levels timer interval, from 1 to 255 sec |
Programmable 256 levels timer interval, from 1 to 255 sec |
Programmable 256 levels timer interval, from 1 to 255 sec |
Programmable 256 levels timer interval, from 1 to 255 sec |
Programmable 256 levels timer interval, from 1 to 255 sec |
Programmable 256 levels timer interval, from 1 to 255 sec |
