Part Number

MIO-3260C-S8A1E

MIO-3260CZ22GS8A1E

MIO-3260L-S3A1E

Processor

CPU

Intel Celeron N2930

Intel Celeron N2930

Intel Atom E3825

Frequency

1.83 GHz (Quad-Core)

1.83 GHz (Quad-Core)

1.33 GHz (Dual-Core)

Core Number

4

4

2

L2 Cache

2 MB

2 MB

2 MB

Max Turbo Frequency

2.16 GHz

2.16 GHz

N/A

System Chipset

Intel Atom SoC processor integrated

Intel Atom SoC processor integrated

Intel Atom SoC processor integrated

BIOS

AMI EFI 64 Mbit

AMI EFI 64 Mbit

AMI EFI 64 Mbit

Memory

Technology

DDR3L 1333 MHz

DDR3L 1333 MHz

DDR3L 1066 MHz

Max. Capacity

8GB

8GB

8GB

Socket

1 x 204-pin SODIMM (Support 1.35V DDR3L)

1 x 204-pin SODIMM (Support 1.35V DDR3L)

1 x 204-pin SODIMM (Support 1.35V DDR3L)

Display

Chipset

Intel Gen7 graphic engine

Intel Gen7 graphic engine

Intel Gen7 graphic engine

Graphic Engine

DirectX®11, Open GL3.0, Open CL 1.1, OGLES 2.0;Encode: H.264, MPEG2;Decode: H.264, MPEG2, VC-1, WMV9

DirectX®11, Open GL3.0, Open CL 1.1, OGLES 2.0;Encode: H.264, MPEG2;Decode: H.264, MPEG2, VC-1, WMV9

DirectX®11, Open GL3.0, Open CL 1.1, OGLES 2.0;Encode: H.264, MPEG2;Decode: H.264, MPEG2, VC-1, WMV9

LVDS

Supports single channel 24-bit LVDS up to 1440 x 900 at 60Hz

Supports single channel 24-bit LVDS up to 1440 x 900 at 60Hz

Supports single channel 24-bit LVDS up to 1440 x 900 at 60Hz

VGA

Supports 2560 x 1600 at 60Hz

Supports 2560 x 1600 at 60Hz

Supports 2560 x 1600 at 60Hz

Dual Display

Yes (LVDS+VGA or LVDS+DP/HDMI or VGA+DP/HDMI)

Yes (LVDS+VGA or LVDS+DP/HDMI or VGA+DP/HDMI)

Yes (LVDS+VGA or LVDS+DP/HDMI or VGA+DP/HDMI)

Ethernet

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Controller

Intel i210

Intel i210

Intel i210

Audio

CODEC

Realtek ALC888S

Realtek ALC888S

Realtek ALC888S

Interface

High Definition Audio (HD)

High Definition Audio (HD)

High Definition Audio (HD)

Connector

Line-in, Line out, Mic-in

Line-in, Line out, Mic-in

Line-in, Line out, Mic-in

Watchdog Timer

Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds

Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds

Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds

Storage

mSATA

1 (Supports mSATA or USB interface module or full size miniPCIe, selected by BIOS, default is mSATA)

1 (Supports mSATA or USB interface module or full size miniPCIe, selected by BIOS, default is mSATA)

1 (Supports mSATA or USB interface module or full size miniPCIe, selected by BIOS, default is mSATA)

SATA

1, up to 3Gb/s (300 MB/s)

1, up to 3Gb/s (300 MB/s)

1, up to 3Gb/s (300 MB/s)

Expansion

Mini PCIe

1 x Full-size

1 x Full-size

1 x Full-size

MIOe

SMBus, USB3.0, LPC, 2 x PCIe x1, Line out, DisplayPort/HDMI*, +5 Vsb/+12 Vsb power,Power On, Reset

SMBus, USB3.0, LPC, 2 x PCIe x1, Line out, DisplayPort/HDMI*, +5 Vsb/+12 Vsb power,Power On, Reset

SMBus, USB3.0, LPC, 2 x PCIe x1, Line out, DisplayPort/HDMI*, +5 Vsb/+12 Vsb power,Power On, Reset

64pin connecter A

12V DC input, Inverter, VGA, 2 x USB2.0, 1GbE w/ LED

12V DC input, Inverter, VGA, 2 x USB2.0, 1GbE w/ LED

12V DC input, Inverter, VGA, 2 x USB2.0, 1GbE w/ LED

64pin connecter B

SMBus, I2C, Power/Reset button, HDD/Power LED, 2 x USB2.0, 8-bit GPIO, HD Audio Line-in, Line out,Mic-in, 2 x RS-232/422/485

SMBus, I2C, Power/Reset button, HDD/Power LED, 2 x USB2.0, 8-bit GPIO, HD Audio Line-in, Line out,Mic-in, 2 x RS-232/422/485

SMBus, I2C, Power/Reset button, HDD/Power LED, 2 x USB2.0, 8-bit GPIO, HD Audio Line-in, Line out,Mic-in, 2 x RS-232/422/485

Power

Power Type

Single 12V DC power input

Single 12V DC power input

Single 12V DC power input

Power Supply Voltage

Supports single 12V input, ± 10%

Supports single 12V input, ± 10%

Supports single 12V input, ± 10%

Total peripheral power supply output

5V @ 3A for CPU board and MIOe module totally, 12V @ 2A for MIOe module

5V @ 3A for CPU board and MIOe module totally, 12V @ 2A for MIOe module

5V @ 3A for CPU board and MIOe module totally, 12V @ 2A for MIOe module

Power Consumption (Typical)

4.22W

4.22W

4.47W

Power Consumption (Max)

8.71W

8.71W

7.13W

Power Management

ACPI

ACPI

ACPI

Battery

3V / 210 mAH

3V / 210 mAH

3V / 210 mAH

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

Non-Operational Temperature

-40° C ~ 85° C and 60° C @ 95% RH non-condensing

-40° C ~ 85° C and 60° C @ 95% RH non-condensing

-40° C ~ 85° C and 60° C @ 95% RH non-condensing

Physical

Dimension (mm)

100 x 72 mm (3.9" x 2.8")

100 x 72 mm (3.9" x 2.8")

100 x 72 mm (3.9" x 2.8")

Weight

0.55 kg (1.21 lb), weight of total package

0.55 kg (1.21 lb), weight of total package

0.35 kg (0.77 lb), weight of total package

Total Height

Top Side: 15.7 mm (including heatsink); Bottom Side: 8.5 mm; PCB: 1.6 mm

Top Side: 15.7 mm (including heatsink); Bottom Side: 8.5 mm; PCB: 1.6 mm

Top Side: 15.7 mm (including heatsink); Bottom Side: 8.5 mm; PCB: 1.6 mm
