Part Number

AIMB-585L-00A1E

AIMB-585QG2-00A1E

AIMB-585WG2-00A1E

Form Factor

Form Factor

Micro ATX

Micro ATX

Micro ATX

Processor

CPU

Intel® Core? i7/i5/i3/Pentium

Intel® Core? i7/i5/i3/Pentium

Intel Xeon/ Core i7/ i5/ i3/ Pentium/ Celeron

CPU TDP

65W / 35W

65W / 35W

80W/65W/35W

BIOS

AMI EFI 128Mbit

AMI EFI 128Mbit

AMI EFI 128Mbit

Core Number

43500

43500

43500

Frequency

2.3GHz ~ 3.6GHz

2.3GHz ~ 3.6GHz

2.3GHz ~ 3.6GHz

L3 Cache

2 ~ 8MB

2 ~ 8MB

2 ~ 8MB

Chipset

Intel H110

Intel Q170

Intel C236

Memory

Max. Capacity

32 GB

64 GB

64 GB

Technology

DDR4 2133MHz

DDR4 2133MHz

DDR4 2133MHz

ECC Support

No

No

Yes/NO

Socket

2 x 288 pin DIMM

4 x 288-pin DIMM

4 x 288-pin DIMM

Display

Controller

Intel HD Graphics

Intel HD Graphics

Intel HD Graphics

Graphic Engine

DirectX11.1, Open GL 4.0

DirectX11.1, Open GL 4.0

DirectX11.1, Open GL 4.0

Graphic Memory

1GB maximum shared memory with 2GB and above system memory installed

1GB maximum shared memory with 2GB and above system memory installed

1GB maximum shared memory with 2GB and above system memory installed

VGA

Up to 1920 x 1200 at 60 Hz

Up to 1920 x 1200 at 60 Hz

Up to 1920 x 1200 at 60 Hz

LCD (TTL/LVDS/eDP)

eDP: support to 3840 x 2160 @ 60 Hz

eDP: support to 3840 x 2160 @ 60 Hz

eDP: support to 3840 x 2160 @ 60 Hz

DDI (HDMI/DVI/DisplayPort)

HDMI: upto 4096x2160 @60Hz / DVI: 1920x1080 @60Hz / DP: 4096x2304 @60HZ

HDMI: upto 4096x2160 @60Hz / DVI: 1920x1080 @60Hz / DP: 4096x2304 @60HZ

HDMI: upto 4096x2160 @60Hz / DVI: 1920x1080 @60Hz / DP: 4096x2304 @60HZ

Multiple Display

Dual

Dual/ Triple

Dual/ Triple

Expansion

PCI Express x 16

1

1

1

PCI Express x 8

0

1

1

PCI Express x 1

2

1

1

PCI Express x 4

0

1

1

SMBus

1

1

1

Audio

Audio Interface

HD Audio

HD Audio

HD Audio

CODEC

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Realtek ALC892, High Definition Audio (HD)

Connector

2 (Line out, Mic-in)

2 (Line out, Mic-in)

2 (Line out, Mic-in)

Ethernet

Controller

Intel i219

LAN1: Intel i219LM / LAN2: Intel i211AT

GbE1: Intel i219LM; GbE2: Intel i210

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Connector

RJ45 x 1

RJ45 x 2

RJ45 x 2

Watchdog Timer

WatchDog Timer

Yes

Yes

Yes

Storage

SATA

3 x SATA III (Max. Data Transfer Rate 600 MB/s)

4 x SATA III (Max. Data Transfer Rate600 MB/s)

4 x SATA III (Max. Data Transfer Rate600 MB/s)

RAID

None

Software RAID 0, 1, 5, 10

Software RAID 0, 1, 5, 10

I/O

GPIO

16-bit GPIO

16-bit GPIO

16-bit GPIO

USB3.0

4

12

12

USB2.0

4

2

2

COM Port

6 ( 5 x RS232, 1 x RS232/ 422/ 485)

6 ( 5 x RS232, 1 x RS232/ 422/ 485)

6 ( 5 x RS232, 1 x RS232/ 422/ 485)

Keypad

1

1

1

TPM

Optional

Optional

Optional

Smart Fan

5

5

5

Power

Power Type

ATX

ATX

ATX

Connector

ATX24P

ATX24P

ATX24P

Power Consumption (Full Load)

3.66A @ 5V / 1.05A @ 3.3V / 6.02A @12V / 0.29A @ 5Vsb / 0A @ -12V /2.88A @ 5V / 1.06A @ 3.3V / 3.3A @12V / 0.36A @ 5Vsb / 0.01A @ -12V

3.66A @ 5V / 1.05A @ 3.3V / 6.02A @12V / 0.29A @ 5Vsb / 0A @ -12V /2.88A @ 5V / 1.06A @ 3.3V / 3.3A @12V / 0.36A @ 5Vsb / 0.01A @ -12V

3.66A @ 5V / 1.05A @ 3.3V / 6.02A @12V / 0.29A @ 5Vsb / 0A @ -12V /2.88A @ 5V / 1.06A @ 3.3V / 3.3A @12V / 0.36A @ 5Vsb / 0.01A @ -12V

Battery

Lithium 3 V / 200 mAh

Lithium 3 V / 200 mAh

Lithium 3 V / 200 mAh

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

Non-Operational Temperature

-20 ~ 70° C (-4 ~ 158F) and 60° C @ 95% RH Non-Condensing

-20 ~ 70° C (-4 ~ 158F) and 60° C @ 95% RH Non-Condensing

-20 ~ 70° C (-4 ~ 158F) and 60° C @ 95% RH Non-Condensing

Vibration Resistance

3.5 Grm (Non-Operation Mode)

3.5 Grm (Non-Operation Mode)

3.5 Grm (Non-Operation Mode)

Physical

Dimension (mm)

244 x 244 mm

244 x 244 mm

244 x 244 mm

Weight

1.2 kg (2.64 lb), weight of total package

1.2 kg (2.64 lb), weight of total package

1.2 kg (2.64 lb), weight of total package

Operating System

Microsoft Windows

Yes

Yes

Yes

Linux

Yes

Yes

Yes

SUSIAccess

Yes

Yes

Yes

Certification

EMC

CE, FCC

CE, FCC

CE, FCC
