Part Number

AIMB-586WG2-00A1E

AIMB-586QG2-00A1E

AIMB-586L-00A1E

Form Factor

Form Factor

Micro ATX

Micro ATX

Micro ATX

Processor

CPU

Intel Xeon/ Core i7/ i5/ i3/ Pentium/ Celeron

Intel® Core? i7/i5/i3/Pentium

Intel® Core? i7/i5/i3/Pentium

CPU TDP

80W/65W/35W

80W/65W/35W

80W/65W/35W

BIOS

AMI EFI 128Mbit

AMI EFI 128Mbit

AMI EFI 128Mbit

Core Number

37352

37352

37352

Frequency

2.2GHz ~ 3.8GHz

2.2GHz ~ 3.8GHz

2.2GHz ~ 3.8GHz

L3 Cache

2 ~ 12MB

2 ~ 8MB

2 ~ 8MB

Chipset

Intel C246

Intel Q370

Intel H310

Memory

Max. Capacity

128GB

128GB

128GB

Technology

Dual Channel DDR4, 2400/2666MHz ECC/Non-ECC with 288 pin U-DIMM

Dual Channel DDR4, 2400/2666MHz ECC/Non-ECC with 288 pin U-DIMM

Dual Channel DDR4, 2400/2666MHz ECC/Non-ECC with 288 pin U-DIMM

ECC Support

Yes

No

No

Socket

4 x 288-pin DIMM

4 x 288-pin DIMM

4 x 288-pin DIMM

Display

Controller

Intel HD Graphics

Intel HD Graphics

Intel HD Graphics

Graphic Engine

DirectX 11.2, OpenGL 5.0, OpenCL 2.1

DirectX11.1, Open GL 4.0

DirectX11.1, Open GL 4.0

Graphic Memory

1GB maximum shared memory with 2GB and above system memory installed

1GB maximum shared memory with 2GB and above system memory installed

1GB maximum shared memory with 2GB and above system memory installed

LCD (TTL/LVDS/eDP)

eDP: support to 3840 x 2160 @ 60 Hz

eDP: support to 3840 x 2160 @ 60 Hz

N/A

DDI (HDMI/DVI/DisplayPort)

HDMI: upto 4096x2160@60Hz ; DP:3840x2160@60Hz

HDMI: upto 4096x2160@60Hz ; DP:3840x2160@60Hz

HDMI: upto 4096x2160@60Hz ; DP:3840x2160@60Hz

Multiple Display

Dual/ Triple

Dual/ Triple

Dual

Expansion

PCI Express x 16

Option

1

1

PCI Express x 8

2

option

0

PCI Express x 1

1

1

0

SMBus

1

1

1

PCI Express x 4

1

1

1

Audio

Audio Interface

HD Audio

HD Audio

HD Audio

CODEC

Realtek ALC888S, High Definition Audio (HD)

Realtek ALC888S, High Definition Audio (HD)

Realtek ALC888S, High Definition Audio (HD)

Connector

2 (Line out, Mic-in)

2 (Line out, Mic-in)

2 (Line out, Mic-in)

Ethernet

Controller

LAN1: Intel i219LM / LAN2: Intel i210AT

LAN1: Intel i219LM / LAN2: Intel i211AT

LAN1: Intel i219LM / LAN2: Intel i211AT

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Connector

RJ45 x 2

RJ45 x 2

RJ45 x 1

Watchdog Timer

WatchDog Timer

Yes

Yes

Yes

Storage

SATA

8 x SATAIII (Max. Data Transfer Rate 600 MB/s)

6 x SATAIII (Max. Data Transfer Rate 600 MB/s)

4 x SATAIII (Max. Data Transfer Rate 600 MB/s)

RAID

Software RAID 0, 1, 5, 10

Software RAID 0, 1, 5, 10

Software RAID 0, 1, 5, 10

I/O

GPIO

16-bit GPIO

16-bit GPIO

16-bit GPIO

USB3.0

6

6

4

USB2.0

6

6

6

COM Port

6(5 x RS-232, 1 x RS-232/422/485)

6 ( 5 x RS232, 1 x RS232/ 422/ 485)

2 ( 5 x RS232, 1 x RS232/ 422/ 485)

Keypad

1

1

1

TPM

Optional

Optional

Optional

Smart Fan

5

5

5

Power

Power Type

ATX

ATX

ATX

Connector

ATX24P

ATX24P

ATX24P

Power Consumption (Full Load)

3.66A @ 5V / 1.05A @ 3.3V / 6.02A @12V / 0.29A @ 5Vsb / 0A @ -12V /2.88A @ 5V / 1.06A @ 3.3V / 3.3A @12V / 0.36A @ 5Vsb / 0.01A @ -12V

3.66A @ 5V / 1.05A @ 3.3V / 6.02A @12V / 0.29A @ 5Vsb / 0A @ -12V /2.88A @ 5V / 1.06A @ 3.3V / 3.3A @12V / 0.36A @ 5Vsb / 0.01A @ -12V

3.66A @ 5V / 1.05A @ 3.3V / 6.02A @12V / 0.29A @ 5Vsb / 0A @ -12V /2.88A @ 5V / 1.06A @ 3.3V / 3.3A @12V / 0.36A @ 5Vsb / 0.01A @ -12V

Battery

Lithium 3 V / 200 mAh

Lithium 3 V / 200 mAh

Lithium 3 V / 200 mAh

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

Non-Operational Temperature

-40 ~ 85° C and 60° C @ 95% RH Non-Condensing

-20 ~ 70° C (-4 ~ 158F) and 60° C @ 95% RH Non-Condensing

-20 ~ 70° C (-4 ~ 158F) and 60° C @ 95% RH Non-Condensing

Vibration Resistance

3.5 Grm (Non-Operation Mode)

3.5 Grm (Non-Operation Mode)

3.5 Grm (Non-Operation Mode)

Physical

Dimension (mm)

244 x 244 mm

244 x 244 mm

244 x 244 mm

Weight

1.2 kg (2.64 lb), weight of total package

1.2 kg (2.64 lb), weight of total package

1.2 kg (2.64 lb), weight of total package

Operating System

Microsoft Windows

Yes

Yes

Yes

Linux

Yes

Yes

Yes

SUSIAccess

Yes

Yes

Yes

Certification

EMC

CE, FCC

CE, FCC

CE, FCC
