Part Number

PCM-3365E-S3A1E

PCM-3365EW-S3A1E

PCM-3365EW-S9A1E

Processor

CPU

Intel Atom E3825

Intel Atom E3825

Intel Atom E3845

Frequency

1.33 GHz

1.33 GHz

1.91 GHz

Max Turbo Frequency

-

-

-

Core Number

2

2

4

L2 Cache

1 MB

1 MB

2 MB

BIOS

AMI UEFI BIOS at 64 Mb

AMI UEFI BIOS at 64 Mb

AMI UEFI BIOS at 64 Mb

Memory

Technology

DDR3L 1066 MHz

DDR3L 1066 MHz

DDR3L 1333 MHz

Max. Capacity

8 GB

8 GB

8 GB

Socket

1 x 204-pin SODIMM

1 x 204-pin SODIMM

1 x 204-pin SODIMM

Display

Controller

Intel Gen7 graphic engine

Intel Gen7 graphic engine

Intel Gen7 graphic engine

Processor Graphics

DirectX11, OpenGL3.2, OpenCL1.1;Full HW acceleration, decode: H.264, MPEG2/4, VC-1, WMV9. Encode: H.264, MPEG2

DirectX11, OpenGL3.2, OpenCL1.1;Full HW acceleration, decode: H.264, MPEG2/4, VC-1, WMV9. Encode: H.264, MPEG2

DirectX11, OpenGL3.2, OpenCL1.1;Full HW acceleration, decode: H.264, MPEG2/4, VC-1, WMV9. Encode: H.264, MPEG2

VGA

2560 x 1600 at 60Hz

2560 x 1600 at 60Hz

2560 x 1600 at 60Hz

LVDS

24-bit LVDS up to WUXGA 1920 x 1200 at 60Hz, Supports single channel 24-bit LVDS up to 1440 x 900 at 60Hz

24-bit LVDS up to WUXGA 1920 x 1200 at 60Hz, Supports single channel 24-bit LVDS up to 1440 x 900 at 60Hz

24-bit LVDS up to WUXGA 1920 x 1200 at 60Hz, Supports single channel 24-bit LVDS up to 1440 x 900 at 60Hz

HDMI

HDMI 1.4a for HD video playback, 1080P at 60Hz, up to 1920 x 1080

HDMI 1.4a for HD video playback, 1080P at 60Hz, up to 1920 x 1080

HDMI 1.4a for HD video playback, 1080P at 60Hz, up to 1920 x 1080

DVI

DVI 1.0 (DVI-D), up to 1920 x 1080

DVI 1.0 (DVI-D), up to 1920 x 1080

DVI 1.0 (DVI-D), up to 1920 x 1080

Multiple Display

VGA + LVDS, VGA + HDMI/DVI, HDMI/DVI + LVDS

VGA + LVDS, VGA + HDMI/DVI, HDMI/DVI + LVDS

VGA + LVDS, VGA + HDMI/DVI, HDMI/DVI + LVDS

Ethernet

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Controller

Intel i210

Intel i210

Intel i210

Connector

Pin Header

Pin Header

Pin Header

Watchdog Timer

Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds

Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds

Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds

Storage

SATA

1, up to 3Gb/s (300 MB/s)

1, up to 3Gb/s (300 MB/s)

1, up to 3Gb/s (300 MB/s)

mSATA

1 x Full-size (SATA signal shared with Onboard flash)

1 x Full-size (SATA signal shared with Onboard flash)

1 x Full-size (SATA signal shared with Onboard flash)

Onboard Flash

16GB/32GB/64GB (support by request)

16GB/32GB/64GB (support by request)

16GB/32GB/64GB (support by request)

Internal I/O

Serial

1 RS-232/422/485 from COM 1, 2 RS-232 from COM2/3 (ESD protection: Air gap ±15kV, Contact ±8kV)

1 RS-232/422/485 from COM 1, 2 RS-232 from COM2/3 (ESD protection: Air gap ±15kV, Contact ±8kV)

1 RS-232/422/485 from COM 1, 2 RS-232 from COM2/3 (ESD protection: Air gap ±15kV, Contact ±8kV)

USB2.0

6

6

6

I2C

1 (Shared with SMBus pin)

1 (Shared with SMBus pin)

1 (Shared with SMBus pin)

SMBus

1

1

1

GPIO

8-bit

8-bit

8-bit

Expansion

Mini PCIe

1 x Full-size (default supports SATA and USB, PCIe is supported by request)

1 x Full-size (default supports SATA and USB, PCIe is supported by request)

1 x Full-size (default supports SATA and USB, PCIe is supported by request)

PC/104

PC/104 Expansion, Memory and DMA are not supported

PC/104 Expansion, Memory and DMA are not supported

PC/104 Expansion, Memory and DMA are not supported

PCI-104

PCI-104 Expansion

PCI-104 Expansion

PCI-104 Expansion

Power

Power Type

AT / ATX

AT / ATX

AT / ATX

Power Supply Voltage

5V ± 5%

5V ± 5%

5V ± 5%

Power Consumption (Typical)

0.877A@+5V, 0.006A@+12V, 0.003A@+5VSB (4.472W)

0.877A@+5V, 0.006A@+12V, 0.003A@+5VSB (4.472W)

0.877A@+5V, 0.006A@+12V, 0.003A@+5VSB (4.472W)

Power Consumption (Max)

1.107A@+5V, 0.008A@+12V, 0.008A@+5VSB (5.671W)

1.107A@+5V, 0.008A@+12V, 0.008A@+5VSB (5.671W)

1.107A@+5V, 0.008A@+12V, 0.008A@+5VSB (5.671W)

Battery

Lithium 3 V / 210 mAH

Lithium 3 V / 210 mAH

Lithium 3 V / 210 mAH

Power Management

ACPI

ACPI

ACPI

Environment

Operational Temperature

0 ~ 60° C with air flow 0.7m/s (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing)

-40° C ~ 85° C

-40° C ~ 85° C

Non-Operational Temperature

-40 ~ 85° C and 60° C @ 95% RH Non-Condensing

-40 ~ 85° C and 60° C @ 95% RH Non-Condensing

-40 ~ 85° C and 60° C @ 95% RH Non-Condensing

Physical

Dimension (mm)

96 x 90 mm (3.8" x 3.5")

96 x 90 mm (3.8" x 3.5")

96 x 90 mm (3.8" x 3.5")

Weight

0.735 kg (1.62 lb) (with heat-sink)

0.735 kg (1.62 lb) (with heat-sink)

0.735 kg (1.62 lb) (with heat-sink)

Total Height

Top side: 14.4mm; Bottom side:7.8mm, PCB: 1.6mm

Top side: 14.4mm; Bottom side:7.8mm, PCB: 1.6mm

Top side: 14.4mm; Bottom side:7.8mm, PCB: 1.6mm
