Part Number

AIMB-286F-00A1E

AIMB-286G2-00A1E

AIMB-286L-00A1E

Processor

CPU

Intel® 8th Gen Core? i processor/Pentium/Celeron (LGA1151)

Intel® 8th Gen Core? i processor/Pentium/Celeron (LGA1151)

Intel® 8th Gen Core? i processor/Pentium/Celeron (LGA1151)

CPU TDP

65W/54W/35W

65W/54W/35W

65W/54W/35W

Frequency

2.1~3.7 GHz

2.1~3.7 GHz

2.1~3.7 GHz

Core Number

2/4/6

2/4/6

2/4/6

BIOS

AMI EFI 128Mbit

AMI EFI 128Mbit

AMI EFI 128Mbit

Chipset

Intel H310

Intel H310

Intel H310

Memory

Technology

DDR4 2666MHz SO-DIMM

DDR4 2666MHz SO-DIMM

DDR4 2666MHz SO-DIMM

Max. Capacity

32GB (up to 16GB per SO-DIMM)

32GB (up to 16GB per SO-DIMM)

32GB (up to 16GB per SO-DIMM)

Socket

2 x 260 Pin DDR4 SO-DIMM

2 x 260 Pin DDR4 SO-DIMM

2 x 260 Pin DDR4 SO-DIMM

Display

Graphic Engine

Intel HD Graphic

Intel HD Graphic

Intel HD Graphic

DDI (HDMI/DVI/DisplayPort)

HDMI:max 4096x2160 @ 24 Hz; DP:4096x2304 @ 60Hz

HDMI:max 4096x2160 @ 24 Hz; DP:4096x2304 @ 60Hz

HDMI:max 4096x2160 @ 24 Hz; DP:4096x2304 @ 60Hz

LVDS

Dual channel 24-bit LVDS, max resolution up to 1920 x 1200 with 60Hz

Dual channel 24-bit LVDS, max resolution up to 1920 x 1200 with 60Hz

N/A

Multiple Display

Dual

Dual

Dual

Video Interface

DP+HDMI, DP+LVDS (or eDP), HDMI + LVDS (or eDP)

DP+HDMI, DP+LVDS (or eDP), HDMI + LVDS (or eDP)

DP+HDMI, DP+LVDS (or eDP), HDMI + LVDS (or eDP)

Expansion

PCI Express x 4

1

1

0

Slot Type

1 x B key (Type: 2242, 3042mm) + 1 x E key (Type: 2230)

1 x B key (Type: 2242, 3042mm) + 1 x E key (Type: 2230)

1 x B key (Type: 2242, 3042mm) + 1 x E key (Type: 2230)

Slots

1 x M.2 B key + 1 x M.2 E key, 1 x PCIex4

1 x M.2 B key + 1 x M.2 E key, 1 x PCIex4

1 x M.2 B key + 1 x M.2 E key

Ethernet

Controller

LAN1/2: Realtek 8111G; LAN3: Intel i211

LAN1/ LAN2: Realtek RTL8111G

LAN1: Realtek 8111G

Speed

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

10/ 100/ 1000 Mbps

Connector

RJ45 x 3

RJ45 x 2

RJ45 x 1

Audio

Audio Interface

HD Audio

HD Audio

HD Audio

CODEC

Realtek ALC888S

Realtek ALC888S

Realtek ALC888S

Connector

2 (Line out, Mic In)

2 (Line out, Mic In)

2 (Line out, Mic In)

Watchdog Timer

WatchDog Timer

Yes

Yes

Yes

Storage

SATA

3 x SATAIII

3 x SATAIII

2 x SATAIII

I/O

COM Port

6 x RS-232 (COM2/3 RS-422/485 supports by optional)

2 x RS-232 (COM2: RS-422/485 supports by optional)

2 x RS-232 (COM2: RS-422/485 supports by optional)

GPIO

16-bit

16-bit

16-bit

USB2.0

4

4

0

TPM

Optional

Optional

0

USB3.0

4

4

4

Power

Connector

DC jack, internal 4pin

DC jack, internal 4pin

DC jack, internal 4pin

Power Type

Single 12V DC power input

Single 12V DC power input

Single 12V DC power input

Environment

Operational Temperature

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

0 ~ 60° C (32 ~ 140° F)

Non-Operational Temperature

-40~ 85° C

-40~ 85° C

-40~ 85° C

Vibration Resistance

3.5 Grms (non OP)

3.5 Grms (non OP)

3.5 Grms (non OP)

Physical

Dimension (mm)

170x 170 mm (without heatsink)

170x 170 mm (without heatsink)

170x 170 mm (without heatsink)

Weight

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

1.04 kg (1.72 lb), weight of total package

Construction

with CPU cooler design

with CPU cooler design

with CPU cooler design

Operating System

Microsoft Windows

Windows 10 (64-bit)

Windows 10 (64-bit)

Windows 10 (64-bit)

Linux

Yes

Yes

Yes

SUSIAccess

Yes

Yes

0

Certification

EMC

CE/FCC Class B

CE/FCC Class B

CE/FCC Class B
